10G AOC OM2

RealSea’s SFP-10G-AOC*M active optical cables are based on 10 Gigabit Ethernet and SFF-8431 standard, and provide a quick and reliable interface for the 10G Ethernet application. The digital diagnostic functions are available via 2-wire serial bus specified in SFF-8472.

Online inquiry Download

Share:

APPLICATION

Data center

Server

Switch

10G Ethernet

Features

STANDARDS COMPLIANCE

PERFORMANCE

General Specifications

Parameter

         Symbol

        Min

           Typ

          Max

       Unit

Data Rate

            DR


           10


       Gb/s

Bit Error Rate

           BER



         1012


Operating Temperature

             TC

              0


            70

       ◦C

Storage Temperature

            TSTO

        -40


            85

       ◦C

Input Voltage

             Vcc

       3.14

           3.30

           3.46

              V

Maximum Voltage          VMAX        -0.5

             4            V
Supply Current            Icc
         180           290         mA



COMPATIBLE BRANDS

Product attributes

Product attributes

Brand

Realsea Technology

Part Number

SFP-10G-AOC*M

Data Rate

10Gbps

Connector Type

SFP+ to SFP+

Cable Length

1~70m

Cable Type

OM2

Minimum Bend Radius

7.5mm

Power Consumption

<0.5W

Jacket Material

PVC (OFNR)

Commercial Temperature

0 to 70°C (32 to 158°F)

Warranty

3 year
